Gigabyte B860M EAGLE PLUS (1.0) (Wi-Fi 6E) DDR5 Intel Core Ultra Motherboard
30,400.00৳
Description
Product Overview
The Gigabyte B860M EAGLE PLUS (1.0) (Wi-Fi 6E) is a high-performance Micro-ATX gaming motherboard built on the Intel B860 Express chipset. Powered by the LGA1851 socket, it natively supports Intel® Core™ Ultra Desktop Processors (Series 2), delivering a future-ready foundation for compact gaming rigs, productivity workstations, and content creation setups.
Equipped with a Digital 8+1+2 Phase VRM design (50A DrMOS) and backed by VRM Thermal Armor Advanced heatsinks, the board delivers steady, clean power delivery and controlled temperatures during heavy processing loads. It features four DDR5 DIMM slots supporting up to 256GB of dual-channel system memory with high-speed memory tuning (up to 9066+ MT/s O.C.) via Intel® XMP 3.0 and AI-enhanced D5 Bionic Corsa technology.
For high-speed expansion and storage, the board features a primary PCIe 5.0 x16 graphics card slot with stainless-steel PCIe Ultra Durable (UD) armor. Storage flexibility is provided by dual M.2 slots—including one hyper-fast PCIe 5.0 x4 M.2 slot and one PCIe 4.0 x4 M.2 slot shielded by an M.2 Thermal Guard heatsink—alongside four SATA 6Gb/s ports with RAID support.
Networking includes Tri-Band Wi-Fi 6E (2.4 / 5 / 6 GHz) with a fast-installation WIFI EZ-Plug antenna, Bluetooth 5.3, and Realtek 2.5GbE LAN for ultra-low latency online gaming. DIY-friendly innovations like PCIe EZ-Latch Plus, M.2 EZ-Latch Plus, EZ-Latch Click, Q-Flash Plus, and Smart Fan 6 make system assembly and BIOS updates smooth and effortless.
Detailed Technical Specifications
| Feature / Attribute | Product Specifications |
| Brand | Gigabyte |
| Model | Gigabyte B860M EAGLE PLUS (1.0) (Wi-Fi 6E) / B860M EAGLE P WIFI6E |
| Chipset | Intel B860 Express |
| CPU Socket | LGA1851 |
| Processor Support | Intel® Core™ Ultra Processors (Series 2) |
| Form Factor | Micro-ATX (24.4cm x 24.4cm) |
| Power Delivery | Digital 8+1+2 Phase VRM Design (50A DrMOS) with VRM Thermal Armor Advanced |
| Memory Type | DDR5 SDRAM |
| Memory Slots | 4 x DDR5 DIMM Slots (Dual-Channel Architecture) |
| Max Memory Capacity | Up to 256GB (Supports up to 9066+ MT/s O.C., Intel® XMP 3.0) |
| Storage Connectors | 2 x M.2 Slots (1x PCIe 5.0 x4 + 1x PCIe 4.0 x4) + 4 x SATA 6Gb/s ports (RAID 0, 1, 5, 10) |
| Expansion Slots | 1 x PCIe 5.0 x16 primary slot (PCIe UD) + 2 x PCIe 4.0 x1 slots |
| Graphics Output | Integrated Intel® HD Graphics Support (1 x HDMI 2.1, 2 x DisplayPort 2.1) |
| Wired Network | Realtek 2.5GbE LAN Chip (2.5 Gbps / 1 Gbps / 100 Mbps) |
| Wireless & Bluetooth | Intel / Realtek Wi-Fi 6E (2.4 / 5 / 6 GHz Tri-Band) + Bluetooth 5.3 |
| USB Connectivity | Rear: USB 3.2 Gen 2 Type-A, USB 3.2 Gen 1, USB 2.0; Front: USB-C 10Gb/s header |
| BIOS & Features | Q-Flash Plus Button, PCIe EZ-Latch Plus, M.2 EZ-Latch Plus, Smart Fan 6, RGB Fusion |
| Audio | Realtek High Definition Audio CODEC (7.1-Channel) |
| Body Color | Black |
| Supported OS | Windows 11 (64-bit), Windows 10 (64-bit) |
| Warranty | 3 Years Official Brand Warranty |
