Product Overview
The Gigabyte GA-H81M-DS2 is a compact Micro-ATX motherboard built around the Intel H81 Express chipset and the LGA1150 socket. Designed to support 4th Generation Intel Core i7, i5, i3, Pentium, and Celeron processors, it provides a stable, budget-friendly foundation for essential home office builds, workstation maintenance, or system replacements on older Intel platforms.
To ensure long-term operational reliability, the board incorporates Gigabyte Ultra Durable™ 4 Plus technology, utilizing solid capacitors, high-efficiency MOSFETs, and a high-density Glass Fabric PCB that protects internal circuits from humidity and electrical shorts. It also features Gigabyte DualBIOS™ technology, incorporating a dedicated backup BIOS chip that automatically restores system firmware in the event of a main BIOS crash or power failure during updates.
Equipped with two 240-pin DDR3 DIMM slots supporting up to 16GB of system memory, two SATA 6Gb/s ports, and two SATA 3Gb/s ports, the GA-H81M-DS2 provides essential connectivity for everyday computing tasks. The rear I/O offers USB 3.0 ports for fast data transfers, high-ESD-protected Gigabit LAN for secure networking, and Gigabyte On/Off Charge™ technology to enable rapid charging of mobile devices even when the PC is powered off, all backed by a 3-year official warranty.
Detailed Technical Specifications
| Feature / Attribute | Product Specifications |
| Brand | Gigabyte |
| Model | Gigabyte GA-H81M-DS2 |
| Chipset | Intel H81 Express |
| CPU Socket | LGA1150 |
| Processor Generation | 4th Generation Intel Core / Pentium / Celeron Processors |
| Form Factor | Micro-ATX (22.6 cm x 17.0 cm) |
| Memory Type | DDR3 SDRAM |
| Memory Slots | 2 x DDR3 DIMM Slots |
| Max Memory Capacity | Up to 16GB (Dual-Channel Architecture) |
| Storage Connectors | 2 x SATA 6Gb/s ports + 2 x SATA 3Gb/s ports |
| Expansion Slots | 1 x PCIe 2.0 x16 slot + 2 x PCIe 2.0 x1 slots |
| Graphics Output | Integrated Intel HD Graphics support (1 x D-Sub / VGA Port) |
| Networking | Realtek GbE LAN Chip (10/100/1000 Mbps) with High ESD Protection |
| USB Support | 2 x USB 3.0 ports (Rear) + 6 x USB 2.0 ports (2 Rear, 4 via internal headers) |
| Audio | Realtek High Definition Audio |
| Color | Black |
| Supported OS | Windows 10, Windows 8.1, Windows 8, Windows 7 |
| Warranty | 3 Years Official Brand Warranty |
