Product Overview

The Gigabyte X870E EAGLE X3D (Wi-Fi 7) is an enthusiast ATX gaming motherboard optimized for high-cache gaming processors and high-end platform performance, powered by AMD’s flagship X870E dual-chipset platform. Built on the Socket AM5 platform, it delivers full native support for AMD Ryzen™ 9000 (including 9000X3D), 8000, and 7000 Series processors, making it a future-proof foundation for ultra-high framerate gaming, 4K streaming, and heavy multithreaded workloads.

Power delivery is driven by a heavy-duty Digital 14+2+2 Twin Phase VRM Design (110A SPS) built on a 6-layer mid-loss PCB, kept cool by VRM Thermal Armor Advanced heatsinks and direct-touch heatpipes. It accommodates four DDR5 DIMM slots supporting up to 256GB of dual-channel system memory with high-speed memory tuning (up to 8000+ MT/s O.C.) enhanced by Gigabyte’s X3D Turbo Mode optimizations, AMD EXPO™, and Intel® XMP profiles.

Expansion options feature a primary PCIe 5.0 x16 graphics card slot protected by PCIe UD Slot X stainless-steel armor. Storage capacity is extensive with four M.2 slots—including two ultra-fast PCIe 5.0 x4 M.2 slots and two PCIe 4.0 x4 M.2 slots covered by M.2 Thermal Guard heatsinks—alongside four SATA 6Gb/s ports with RAID support.

Wireless networking features next-generation Wi-Fi 7 (802.11be, 320MHz channel width) with a high-gain WIFI EZ-Plug antenna, Bluetooth 5.4, Realtek 2.5GbE LAN, and dual USB4® Type-C ports (40Gbps with DP-Alt Mode). DIY-friendly innovations like PCIe EZ-Latch Plus, M.2 EZ-Latch Click, M.2 EZ-Latch Plus, Q-Flash Plus, and Smart Fan 6 make system assembly smooth and straightforward.

Detailed Technical Specifications
