Gigabyte B650M AORUS ELITE AX (Wi-Fi 6E) DDR5 AMD Gaming Motherboard
Your Delivery options
Courier delivery
Courier will deliver to the specified address
2-3 days From 120BDT
Gigabyte B650M AORUS ELITE AX (Wi-Fi 6E) DDR5 AMD Gaming Motherboard
27,900.00৳
Description
Product Overview
The Gigabyte B650M AORUS ELITE AX is a high-tier Micro-ATX gaming motherboard engineered around the AMD B650 chipset. Built for the Socket AM5 platform, it supports AMD Ryzen™ 9000, 8000, and 7000 Series desktop processors, delivering premium power delivery and thermal management in a compact form factor.
Power delivery is handled by a Twin 12+2+1 Phase Digital VRM Design (70A Smart Power Stage) backed by fully covered VRM heatsinks and 6mm heatpipes to maintain low VRM temperatures during long gaming sessions or continuous multi-threaded workloads. It features four DDR5 DIMM slots supporting up to 128GB (or up to 256GB with updated 64GB DIMMs) of dual-channel system memory with AMD EXPO™ and Intel® XMP memory overclocking profiles.
Storage options include dual M.2 slots—one hyper-fast PCIe 5.0 x4 M.2 slot and one PCIe 4.0 x4 slot—both shielded by enlarged M.2 Thermal Guard heatsinks, along with four SATA 6Gb/s ports featuring RAID support.
Networking features onboard Tri-Band Wi-Fi 6E (2.4 / 5 / 6 GHz), Bluetooth 5.2 / 5.3, and Realtek 2.5GbE LAN for lag-free online gaming and fast file transfers. DIY-centric innovations like PCIe EZ-Latch, M.2 EZ-Latch, Q-Flash Plus, and Smart Fan 6 make building and updating the PC seamless.
Detailed Technical Specifications
| Feature / Attribute | Product Specifications |
| Brand | Gigabyte (AORUS) |
| Model | Gigabyte B650M AORUS ELITE AX (Wi-Fi 6E) |
| Chipset | AMD B650 |
| CPU Socket | Socket AM5 |
| Processor Support | AMD Ryzen™ 9000 / 8000 / 7000 Series Processors |
| Form Factor | Micro-ATX (24.4cm x 24.4cm) |
| Power Delivery | Twin 12+2+1 / 12+2+2 Phase Digital VRM (70A SPS) with Fully Covered VRM Heatsinks |
| Memory Type | DDR5 SDRAM |
| Memory Slots | 4 x DDR5 DIMM Slots (Dual-Channel Architecture) |
| Max Memory Capacity | Up to 128GB / 256GB (Supports up to 8000+ MHz O.C., AMD EXPO™ & Intel® XMP) |
| Storage Connectors | 2 x M.2 Slots (1x PCIe 5.0 x4 + 1x PCIe 4.0 x4) + 4 x SATA 6Gb/s ports (RAID 0, 1, 10) |
| Expansion Slots | 1 x PCIe 4.0 x16 slot (PCIEX16) + 1 x PCIe 4.0 x16 slot (running at x4) |
| Graphics Output | Integrated AMD Radeon™ Support (1 x HDMI 2.1, 1 x DisplayPort 1.4) |
| Wired Network | Realtek 2.5GbE LAN Chip (2.5 Gbps / 1 Gbps / 100 Mbps) |
| Wireless & Bluetooth | AMD Wi-Fi 6E RZ616 / Intel Wi-Fi 6E AX210 (2.4/5/6 GHz Tri-Band) + Bluetooth 5.2 / 5.3 |
| USB Connectivity | Rear: 1x USB-C (3.2 Gen 2), 2x USB 3.2 Gen 2 Type-A, 5x USB 3.2 Gen 1, 4x USB 2.0; Front: USB-C 20Gb/s header |
| BIOS & Features | Q-Flash Plus Button, PCIe EZ-Latch, M.2 EZ-Latch, Smart Fan 6, RGB Fusion (ARGB headers) |
| Audio | Realtek High Definition Audio CODEC (7.1-Channel) with Optical S/PDIF Out |
| Body Color | Black / Dark Metal Gray |
| Supported OS | Windows 11 (64-bit), Windows 10 (64-bit) |
| Warranty | 3 Years Official Brand Warranty |
