Product Overview

The Gigabyte B760M GAMING X GEN5 (Wi-Fi 6E) is a high-performance Micro-ATX gaming motherboard built around the Intel B760 Express chipset. Designed for the LGA1700 socket, it provides full native support for 12th, 13th, and 14th Generation Intel® Core™, Pentium® Gold, and Celeron® processors. It provides a feature-rich, high-speed foundation for competitive gaming setups and intensive productivity builds.

Equipped with an 8+1+1 Hybrid Digital VRM Design (60A DrMOS) and VRM Thermal Armor Advanced heatsinks, the motherboard ensures continuous and clean power delivery with low operational temperatures. It features four DDR5 DIMM slots supporting up to 256GB of system memory in dual-channel configuration, with extreme memory overclocking support via Intel® XMP 3.0 profiles.

For expansion, it offers a primary PCIe 5.0 x16 slot with a reinforced Ultra Durable (UD) stainless-steel armor for next-gen graphics cards. High-speed storage is provided by dual PCIe 4.0 x4 M.2 slots protected by thermal guards, along with four SATA 6Gb/s ports.

Comprehensive wireless and wired networking includes Intel Wi-Fi 6E AX210 (supporting the dedicated 6GHz band), Bluetooth 5.3, and Realtek 2.5GbE LAN for ultra-low latency streaming and online gaming. Smart build features like PCIe EZ-Latch, WIFI EZ-Plug, Q-Flash Plus, and multi-display outputs (HDMI 2.1 and DisplayPort 1.2) complete the platform.

Detailed Technical Specifications
